Matseno
Ditlhaloso .
|
Karolo ya No. |
Bogolo bja Flange . |
Hose bore . |
Ditekanyo . |
||||||
|
D n . |
TEŠE |
A |
C |
D |
H |
L |
|||
|
87391-08-08 |
1/2" |
12 |
08 |
41 |
30.2 |
24 |
47 |
6.73 |
|
|
87391-12-08 |
3/4" |
12 |
08 |
41 |
38.1 |
31.7 |
48 |
6.73 |
|
|
87391-12-10 |
3/4" |
16 |
10 |
56.5 |
38.1 |
31.7 |
52.5 |
6.73 |
|
|
87391-12-12 |
3/4" |
20 |
12 |
66.2 |
38.1 |
31.7 |
62 |
6.73 |
|
|
87391-12-12(H100) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
100 |
6.73 |
|
|
87391-12-12(H127) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
127 |
6.73 |
|
|
87391-12-12(H150) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
150 |
6.73 |
|
|
87391-12-16 |
3/4" |
25 |
16 |
76.7 |
38.1 |
31.7 |
67.5 |
6.73 |
|
|
87391-16-12 |
1" |
20 |
12 |
66.2 |
44.4 |
38 |
62 |
8 |
|
|
87391-16-16 |
1" |
25 |
16 |
78 |
44.4 |
38 |
67.5 |
8 |
|
|
87391-16-16(H100) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
100 |
8 |
|
|
87391-16-16(H127) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
127 |
8 |
|
|
87391-16-16(H150) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
150 |
8 |
|
|
87391-16-20 |
1" |
32 |
20 |
91.5 |
44.4 |
38 |
78.5 |
8 |
|
|
87391-20-16 |
1.1/4" |
25 |
16 |
78 |
50.8 |
43 |
67.5 |
8 |
|
|
87391-20-20 |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
78.5 |
8 |
|
|
87391-20-20(H100) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
100 |
8 |
|
|
87391-20-20(H127) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
127 |
8 |
|
|
87391-20-20(H150) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
150 |
8 |
|
|
87391-20-24 |
1.1/4" |
40 |
24 |
108.5 |
50.8 |
43 |
78.5 |
8 |
|
|
87391-24-20 |
1.1/2" |
32 |
20 |
91.5 |
60.3 |
50 |
80.5 |
8 |
|
|
87391-24-24 |
1.1/2" |
40 |
24 |
109.4 |
60.3 |
50 |
94 |
8 |
|
|
87391-24-24(H127) |
1.1/2" |
40 |
24 |
109.4 |
60.3 |
50 |
127 |
8 |
|
|
87391-32-24 |
2" |
40 |
24 |
109.4 |
71.4 |
62 |
94 |
9.53 |
|
|
87391-32-32 |
2" |
50 |
32 |
131.8 |
71.4 |
62 |
114.3 |
9.53 |
|
|
87391-40-32 |
2.1/2" |
50 |
32 |
131.8 |
84.1 |
74.4 |
114.3 |
9.53 |
|
Ditekanyetšo/Data ya Sethekniki .
|
Mathomo |
Zhejiang, China e ile ya nyoba ntša. |
Letšatšikgwedi la thomelo . |
Go ka boledišanwa . |
|
Setifikeiti sa . |
GB / T19001-2016 IDT ISO9001:2015 |
Go paka . |
Maemo a Thomelontle . |
|
Didirišwa |
Tšepe ya khabone . |
Tiisetso ya . |
Ngwaga o tee . |
|
Lereo la tefo . |
TT . |
MOQ . |
2000 |
|
Peelano |
Mpsha |
Mmala |
zinki e tšoeu, zinki ea mmala . |
Mabapi le Khamphani .
Melemo .
Intasteri-Tebetšo ya kgatelelo ye e etilego pele .
E hlamilwe go kgotlelela kgatelelo ya go šoma ya go fihla go 15,000 PSI .
40% ya godimo ya tekanyetšo ya kgatelelo ya go thuthupa go feta maemo a intasteri .
Kgatelelo yeo e nago le tokelo ya go ba le tokelo ya go ba le tokelo ya go lekalekanya ya maemo a feteletšego .
Bokgoni bja tšweletšo ya go nepagala .
CNC machining le ± 0.0.001" kgotlelelo taolo .
100% Go kgokaganya motšhene wa go ela (CMM) netefatšo .
Tlhahlobo ya Optical ya go itiriša bakeng sa diphetho tše di phethagetšego tša bokagodimo .
Saense ya Dilo tše di bonagalago ya maemo a godimo .
Aerospace-ditswaki tša maemo a godimo tšeo di nago le kganetšo ya go lapa ye e kaonafetšego .
Tšhilafatšo ya mong-Ditlhamo tša tšhipi tše di lwantšhago .
Full material traceability ho tloha Mill ho qeta producv .
Tikologo-e nago le bogwera .
Ka mehla re šomiša kota ya tlhago le kota bjalo ka didirišwa, ntle le go kopanya goba tshepedišo ya dikhemikhale, yeo e lego ya tlhago, tikologo-e nago le bogwera le ya boleng bjo bobotse. Efa legae la gago go kgoma le moya o mobotse kudu .
Go swarelela mo go sa bapišwego .
Ka mehla re šomiša kota ya tlhago le kota bjalo ka didirišwa, ntle le go kopanya goba tshepedišo ya dikhemikhale, yeo e lego ya tlhago, tikologo-e nago le bogwera le ya boleng bjo bobotse. Efa legae la gago go kgoma le moya o mobotse kudu .
Kobamelo ya Maemo a feletšego .
E netefaditšwe go maemo a SAE, ISO, DIN, le ASME .
PED, ATEX, le API 6A dikgetho tse latelang .
ABS/DNV ditumelelo tša lewatleng tše di lego gona .
Melemo ya tlhomamiso .
Mmala-o ngwadilwe ka sehlopha sa kgatelelo bakeng sa go hlaola gabonolo .
Quick-Kgokaganya meralo ka tlhomelo ya 60% ya ka pela .
Ditšhupetšo tša Torque tše di Kopantšwego tša Kopano ye e swanetšego .
Bokgoni bja boentšeneare bja tlwaelo .
Ditharollo tša tshepedišo tše di feletšego go tloga go 1/8" go ya go 6 "bogolo .
Didirišwa tša ka ntle go akaretša Monel, Inconel, le Stellite .
CAD-Dipeakanyo tša tlwaelo tše di loketšego .
Netefatšo ya Boleng ye e Tiilego .
100% ya teko ya hydrostatic ka 1.5x ya go šoma kgatelelo .
Ultrasonic le makenete dikarolwana tlhahlobo .
Lot-Tšweletšo ye e laolwago ka go latišišwa ka botlalo .
Thekgo ya Sethekniki ya Lefase ka Bophara .
24/7 Thušo ya Boentšenere .
On-Ditlhahlobo tša Tshepedišo ya Lefelo tše di lego gona .
Tlwaetšo ya go hloma ya kgonthe ya go bonagala .
FAQ .
Q: Ke maemo afe ao didirišwa tša gago tša haeteroliki le di-flanges di dumelelanago le tšona?
A: Ditšweletšwa tša rena di fihlelela maemo a intasteri ya lefase ka bophara, go akaretšwa:
SAE J514, J518, J1453.
ISO 8434, 6162, 12151 .
DIN 2353, 20066 .
A SM ea B16,5, B16,47 .
ANSI, NFPA, le ditlhaloso tša API .
Q: Ke ditekanyo dife tša kgatelelo tšeo di lego gona?
A: Re fana ka dithusaleago le flanges bakeng sa mefuta e fapaneng khatello ea mekhahlelo:
Low-kgatelelo ( ka fase ga goba e lekana le 3,000 psi / 207 bar) – ditshepedišo tša haeteroliki tša maemo .
Medium-kgatelelo (3,000–6,000 psi / 207–414 bar) – Dihaetereliki tša intasteri & tša sellathekeng .
High-kgatelelo (6,000–15,000 psi / 414–1,034 bar) – oli & khase, sefofane, le metšhene e boima
Q: Ke didirišwa dife tšeo di šomišwago ka gare ga didirišwa tša gago tša go tsenya le diflantšhe?
A: Didirišwa tše di lego gona di akaretša:
Tšhipi ya khapone – zinki-e plated goba fosfate-e tloditšwe
Tšepe e sa tsoaneng (304/316) – Tšhilafalo-e hanyetsang bakeng sa ditikologo tse thata
Alloy Steel (Aisi 4130, 4140) – High-matla a kgateletšo e feteletšego .
Ditswaki tša ka ntle (inconel, Monel, Titanium) – bakeng sa go ganetša ga dikhemikhale/go fiša .
Q: Ke kgetha bjang go lokela goba flange ya maleba bakeng sa tshepedišo ya ka?
A: Mabaka a bohlokwa ao a swanetšego go elwa hloko:
Mofuta wa khoele (NPT, BSPP, BSPT, METRIC, ORFS, jj.) .
Bogolo (1/8" go ya go 6") .
Tekanyetšo ya kgatelelo .
Go sepelelana ga seela .
Maemo a tikologo (thempheretšha, tšhilafalo, thothomelo) .
Baentšeneare ba rena ba fana ka thušo ya go kgetha ya mahala.
Q: Na dilo tša gago tša go tsenya di a fapantšhwa le ditšweletšwa tše dingwe?
A: Ee – Ditšweletšwa tša rena di hlamilwe go ba tšeo di fetošetšwago ka botlalo le didirišwa tša SAE/ISO/DIn-tšeo di sepelelanago.
ELA HLOKO: Ka mehla netefatša mohuta wa khoele le mokgwa wa go tiiša bakeng sa go sepelelana.
Q: Ke mekgwa efe ya go tiiša yeo e lego gona?
A: Re fana ka dikgetho multiple tiiso:
o-tiiso ya sefahleho sa lesale (ORFs) – e molemo ka ho fetisisa bakeng sa phahameng-kgatelelo, ho dutla-dikgokelo tsa bohlatse
Tapered khoele (NPT, BSPT) – tšepe - ho - tšepe tiiso .
Sefahleho se bataletseng ka gasket (SAE/ISO Flange) – bakeng sa dikgokelo tsa flange .
Loma -Mohuta (Din 2353) – Ferrule-Setiago se se theilwego godimo ga .
Q: Nako ya go eta pele ya ditaelo tša maemo vs. tlwaelo?
A: Standard dithusaleago: 1-3 matsatsi a (ka setokong) .
Ditaelo tša tlwaelo/tše di kgethegilego: dibeke tše 2–4 (go ya ka go raragana) .
Ditirelo tše di akgofilego: di hwetšagala bakeng sa dinyakwa tša ka pela .
Q: Na o fana ka tlhahlo ya go hloma?
A: Ee! Re fana ka:
Mohato -ka-Dibuka tsa tlhomamiso tsa kgato .
Torque Ditlhaloso & Tightening Tatelano .
Bidio dithuto & 3D kopano tataiso .
On-Thekgo ya Mothekniki ya Sebaka (ya boikgethelo) .
Q: Ke ditifikeiti dife tšeo o di swerego?
A: Dinolofatši tša rena le ditšweletšwa di netefaditšwe go:
ISO 9001:2015 (Taolo ya Boleng) .
PED 2014/68/EU (Taelo ya Didirišwa tša Kgateletšo) .
ATEX (Dipapatšo tša go thuthupa) .
ABS, DNV, & Lloyd's Register (Dikopo tsa Lewatle) .
Q: Ke tlhokomelo efe yeo e nyakegago bakeng sa didirišwa tša haeteroliki?
A: Tlhokomelo e kgothaleditšwego e akaretša:
Ditšheke tša ngwaga le ngwaga tša torque .
Go tšeelwa legato ga tiišo ya ngwaga le ngwaga .
Tlhahlobo ya pono ya go tšhungwa/apara .
Teko ya ultrasonic bakeng sa ditshepedišo tša kgatelelo ya godimo{0}}
